Model	JY915-P
Size	≤8100×2700×3400mm	Bucket capacity	≥0.4m³
Weight	≤15000kg	Crushing hammer diameter	≥60mm
Operating radius	≥4000mm	Power	≥84kw
Clamping weight	2000KG	Remote control distance	2000m
Optional devices	hydraulic shears, hydraulic clamps, gas detection device.



（1） Technical performance
1. Remote wireless remote control capability
Support beyond line of sight remote control, with a maximum control range of 1-2 kilometers, and can optimize signal transmission according to actual conditions to adapt to different terrain environments.
2. Real time monitoring and environmental detection
The vehicle is equipped with 9 high-definition cameras to achieve all-round (front, rear, left and right, top) monitoring, ensuring the safety and accuracy of the operation process.
Drone detection system: It can conduct terrain survey of the work area before operation, improving the accuracy of task planning.
Gas sensor: capable of detecting oxygen concentration, combustible gases, and ambient temperature, and providing real-time data feedback to support operational safety.
3. Strong homework ability
Dual operation device design: The front-end is equipped with a digging device, which can be quickly replaced and adapted to different operation needs; The backend comes standard with hydraulic shears, suitable for complex working environments.
Adapting to extreme working conditions, it can perform various tasks such as obstacle clearance, demolition, and transportation, improving the efficiency of emergency rescue.
4. High maneuverability and stability
The curb weight of the entire vehicle is ≥ 13t, ensuring stability and operational load capacity.
The body size (≤ 8100 × 2700 × 3400mm) meets the mobility requirements for transportation and complex environments.
The engine power is ≥ 84kW, providing strong power to ensure operational stability and passability.



（2） Product advantages
1. Remote control to enhance safety
Through wireless remote control, operators can stay away from dangerous areas for precise operations, reducing personnel risks.
2. Intelligent detection to improve decision-making efficiency
By combining high-definition cameras, drone detection, and gas sensing technology, real-time environmental data can be obtained to provide scientific decision-making support for emergency operations.
3. Modular design to adapt to various task requirements
It can quickly replace the operating equipment and adapt to different scenarios, such as demolition, excavation, and transportation, to improve equipment utilization.
4. Comprehensive monitoring to ensure accuracy of operations
Nine high-definition cameras provide a 360 ° viewing angle, ensuring the operator has comprehensive control over the environment and work conditions.
5. Strong power and high passability, suitable for complex terrain
Adopting a powerful power system and stable chassis design, it can operate efficiently in various complex terrain conditions.


Support beyond line of sight remote control, with a maximum control range of 1-2 kilometers, and can optimize signal transmission according to actual conditions to adapt to different terrain environments
